| Item | General Parameter | Remark |
| Rated Capacity | 230Ah | |
| Nominal Voltage | 3.2V | |
| Discharge Cut-off Voltage | 2.5V | |
| Charge Cut-off Voltage | 3.65V | |
| Internal Impedance | ≤0.25mΩ | |
| Standard Charge | 0.5C | |
| Standard Discharge | 0.5C | |
| Maximum Continuous Charge Current | 1.0C | |
| Maximum Continuous Discharge Current | 1.0C | |
| Instantaneous Discharge Current | 2.0C | 60s |
| Cycle Life | ≥3500cycles | 25℃，80%DOD，1.0C/1.0C |
| Recommend Operation Temperature Range | Charge：0-60℃ | |
| Discharge：-30-60℃ | ||
| Recommend Storage Temperature Range | Less than 1 year：0-35℃ | 60±25%R.H. Bare Cell Storage Humidity Range |
| less than 1 month：-20-45℃ | ||
| Cell Weight | 4.11±0.10Kg |
