| Item | General Parameter | Remark |
| Rated Capacity | 100Ah | |
| Nominal Voltage | 3.2V | |
| Discharge Cut-off Voltage | 2.5V | |
| Charge Cut-off Voltage | 3.65V | |
| Internal Resistance | ≤0.4mΩ | |
| Standard Charge | 0.5C | |
| Standard Discharge | 0.5C | |
| Max Continuous Charge Current | 1.0C | |
| Max Continuous Discharge Current | 3.0C | |
| Pulse Discharge Current | 10.0C | 5s |
| Cycle Life | ≥2500cycles | FC/1C，25℃，80%DOD |
| Recommended Operating Temperature Range | Charge：-20-55℃ | |
| Discharge：-40-60℃ | ||
| Storage Temperature Range | -40-60℃ | 60±25%R.H. Bare Cell Storage Humidity Range |
| Cell Weight | 2035±30g | |
| Cell Dimensions | Height：119.0±0.5mm | With Terminal |
| Height：116.8±0.5mm | Without Terminal | |
| Length：148.6±0.5mm | / | |
| Thickness：52.3±0.3mm | / |
