| Item | General Parameter | Remark |
| Rated Capacity | 200Ah | |
| Nominal Voltage | 3.2V | |
| Discharge Cut-off Voltage | 2.5V | |
| Charge Cut-off Voltage | 3.65V | |
| Internal Impedance | ≤0.3mΩ | |
| Standard Charge | 0.5C | |
| Standard Discharge | 0.5C | |
| Maximum Continuous Charge Current | 1.0C | |
| Maximum Continuous Discharge Current | 1.0C | |
| Instantaneous Discharge Current | 3.0C | 10s |
| Cycle Life | ≥3000cycles | 25℃，80%DOD，0.5C/0.5C |
| Recommend Operation Temperature Range | Charge：0-60℃ | |
| Discharge：-20-60℃ | ||
| Recommend Storage Temperature Range | Less than 1 year：-20-35℃ | 60±25%R.H. Bare Cell Storage Humidity Range |
| less than 1 month：-30-45℃ | ||
| Cell Weight | 4.1±0.15Kg |
