| Model | GBSFP48100T |
| Height 19" rack | 3U (19" rack) |
| Nominal voltage | 48Vdc |
| Equilization charge voltage | 53.3Vdc |
| Floating charge voltage | 51.0Vdc |
| Cutoff discharge voltage | 40.5Vdc |
| Max charge/discharge current | 100A / 100A, @25℃ |
| Charging current limiting | 10A |
| Weight | 43kg |
| Size (W*D*H) | 442mm*420mm*133mm 482 depth include handles,terminals |
| Self discharge @25℃ | < 5% in 90-day storage |
| Comm. way | RS485, RS232 |
| Function | Over tempt, over current, short circuit, over discharge etc. |
| Cycle life | 3000 cycles (25℃ / 80%DOD) |
| Working humidity | Charge: 0℃～65℃; Discharge: -20℃～65℃ |
| Design Life | 10 Years |
